Samsung SSA-P421 Intelligent Four Door Controller TCP/IP with Power Supply (MIFARE FORMAT)

Key Features

• Intelligent 4 Doors Access Control Panel with Power Package
• Up 50,000 Users and up to 29,500 Event Buffers
• Network Communication via RS232 / RS422 / RS485,TCP/ IP (SSA-P420T/P421T)
• Independent 15 Inputs and 15 Outputs including 12ea of 2 Form-C Relay Outputs
• 4ea of Reader Port for Anti-passback Function : 26bit / 34bit Wiegand and 4 / 8bit Burst for PIN
• 2 Men Operation
• ARM / DISARM Function for Alarm Panel
• 2 Levels Individual Door Opening Time Setting available for handicapped person
• Remain ID & Event Data and Setting Value in case of Electric Outage
• Duress Mode Function
• Check Supervisory signal from Reader (Cut off check)
• Alarm Event Monitoring using Tamper Switch
• Communication Status via LED Indicator
